The 4 ZONE™ antenna combiner takes the complexity out of multizone wireless microphone projects. This wideband combiner (470-960 MHz) brings together up to four separate pairs of diversity antenna connections for multipurpose rooms, indoor-outdoor configurations, or main stages with secondary breakout rooms.
For fine tuning RF levels in each coverage area, 4 ZONE provides individual channel RF signal attenuation control down to -31dB in 1 dB steps. And for active antennas or in-line amplifiers, it features selectable 12V DC power to accommodate long cable runs.
With selectable on/off inputs, 4 ZONE also allows for quick control of coverage zones for roaming microphone transmitters, so you can choose which zones are active. When used in conjunction with up to four Diversity Fin Antennas and one or more DISTRO4 antenna distributors, 4 ZONE completes a turnkey package for any multizone wireless microphone project.
Wideband antenna combiner (470-960 MHz) brings together up to four separate pairs of diversity antenna connections for multipurpose rooms, indoor-outdoor configurations, or main stages with secondary breakout rooms
Individual channel RF signal attenuation for fine tuning of RF levels in each coverage area
Selectable on/off inputs allow for quick control of coverage zones so you can choose which zones are active
12V antenna power on each input for active in-line RF accessories
Integrated power supply (no wall wart)
Front-panel LED antenna/power status indicators
Includes one AC cable and two BNC-to-BNC coaxial cables
Full rack width (1 RU)
Operating frequency: 470 to 960 MHz
Full system gain: : 3 dB (±3 dB)
Input/output impedance: 50 ohms
A/B antenna input: 4 + 4
OIP3: 35 dBm (typ.) @ 2-tone; Pi=-15 dBm/tone
RF input attenuation: -31 ~0 dB (step: 1 dB)
Input connectors: BNC female (x 8)
Output connectors: BNC female (x 2)
In-line amplifier power: 12V/200 mA*8
Power supply: 100-240V AC, 50/60 Hz, max 2A:
Dimensions: 480 mm (18.90") W x 260 mm (10.24") D x 45 mm (1.77")H
Accessories included: AC cable; BNC-to-BNC coaxial cable (x 2)
