MC4000 PREMIUM CONTROLLER

A peerless combination of features and build quality for professionals. The Denon MC4000 premium controller is an exciting addition to Denon DJ’s distinguished line of professional DJ products. Featuring a sleek new design and inviting appearance, the MC4000 premium controller continues Denon DJ’s reputation for innovative features, dependability, unrivaled sound quality and peerless value.

Features:

Premium 2-Deck controller for Serato
Includes Serato DJ Intro; user-upgradeable to Serato DJ
Touch-activated jog wheels for accurate scratching and track cueing
Dedicated Hot Cue and sample trigger pads with illuminated feedback
Long-throw 100mm pitch faders
Balanced Booth Outputs for local monitor speakers, with independent level control
Spacious control layout for effortless, optimized workflow
Dedicated EQ and FX controls on each channel
(2) Balanced mic inputs with 2-band EQ, Ducking, and Echo effect
RCA Aux input for external device mixing
Balanced Main and Booth Outputs
Pro-grade steel construction ensures long-term durability
Compatible with Traktor 2 (via .tsi files), Algoriddim djay Pro and Virtual DJ 8

Specifications:

USB Audio / MIDI Interface

USB 2.0
Sampling Rate: 44.1, 48 kHz (0 channels in, 4 channels out)
Bit Depth: 24 bit

Frequency Response:
20 Hz – 20 kHz (+1.0 dB)

Dynamic Range:
Digital-to-Analog Converter: > 112 dB (A-weighted)
Total: > 105 dB (A-weighted)

Signal-to-Noise Ratio:
> 88 dB, A-weighted
Headroom:

Aux Input: > 17 dB
Mic Input: > 20 dB
Outputs: > 20 dB
THD+N:

< 0.01% (1 kHz at unity)

Channel Separation:
< -80 dB (1 kHz at unity)

Analog Input:
Microphone: -60 dBu (minimum), -40 dBu (unity)
Aux: +17 dBV (maximum), 0 dBV (unity)

Analog Output:
Master (XLR): +24 dBu (maximum), +4 dBu (unity)
Master (RCA): +19 dBu (maximum), 0 dBu (unity)
Booth: +24 dBu (maximum), +4 dBu (unity)

Headphone: > 100 mW at 40 ?

Microphone Input:
Equivalent Input Noise: < -116 dBu (Rs = 150 ?, DIN)
Common Mode Rejection Ratio: > 75 dB

Microphone Effects:
Talkover: -20 dB attenuation, 40 ms attack time, 250 ms hold time, 100 ms release time
Echo: 199 ms rate, -6 dB feedback, -? to 0 dB range (-9 dB center)
EQ: +15 dB high band (1 kHz cutoff), +15 dB low band (1 kHz cutoff)

Unit Size:
19.9 (W) x 12.3 (D) x 2.7 (H) (Inches)
505 (W) x 312 (D) x 69 (H) (Millimeters)

Unit Weight:
8.95 lbs
4.06 kg

Unit Weight with Carton:
13.22 lbs
6.0 kg

Supported Operating Systems:
Mac OS X: 10.8, 10.9, 10.10
Windows: 7, 8, 8.1

Supported Processors:
i3, i5 or i7 32 & 64 bit: 1.07 GHz+
Core 2 Duo 32 bit: 2.0 GHz+ 64 bit: 2.4 GHz+
Minimum RAM:

32 bit OS: 2 GB
64 bit OS: 4 GB
USB:

1 available USB 2.0 port
Note: Intel Processors are required for use with Serato DJ Software

Denon DJ MC-4000 (Denon MC4000)
