The new CUEPIX Par 300â„¢ features (7) long life 30W 3-in-1 RGB COB LEDs, 100,000 average hour LED life, 15° beam angle, individual control of each COB module, variable dimming curve modes, strobe and chase effects, ArtNetâ„¢, KlingNetâ„¢ and RDM (remote device management) protocol support, 3pin and 5pin DMX, powerCon, and RJ45 in/out connections, LCD menu display with 4 button control panel, integrated rigging bracket, multiple unit power linking, rugged die-cast aluminum exterior, flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (110-240v).
FEATURES
15° Beam / 25° Field Angles
ArtNetâ„¢ and Klingnetâ„¢ Support
RDM - Remote Device Management
Individual COB Module Control
Variable Dimming Curve Modes
Multiple Unit Power Linking
Rugged Die-Cast Aluminum Exterior
Flicker Free Operation for TV and FILM
SOURCE
(7) 30W 3-in-1 COB LEDs
100,000 Hour Average LED Life
PHOTOMETRIC DATA
24,200 LUX 2,2248 FC @3.3’ (1m) (15° Full ON)
7,110 LUX 661 FC @6.6’ (2m) 15° Full ON)
3,230 LUX 300 FC @9.8’ (3m) (15° Full ON)
1,925 LUX 179 FC @13.1’ (4m) (15° Full ON)
1,250 LUX 116 FC @16.4’ (5m) (15° Full ON)
EFFECTS
Strobe and Chase Effects
Individual COB Module Control
Variable Dimming Curve Modes
CONTROL / CONNECTIONS
6 DMX Channel Modes (3 / 4 / 5 / 9 / 21 / 24)
4 Button Control Panel and LCD Menu Display
ArtNetâ„¢ + KlingNetâ„¢ Protocol Support
RDM (Remote Device Management)
(2) RJ45 Ports
3pin and 5pin DMX In/Out
powerCON Power In/Out
SIZE / WEIGHT
Length: 14.4" (365mm)
Width: 5.8" (147mm)
Vertical Height: 14.4" (365mm)
Weight: 17.0 lbs. (7.7 kg)
ELECTRICAL / THERMAL
AC 110-250V - 50/60Hz
Max Power Consumption: 300W
68°F to 113°F (20°C to 45°C)
APPROVALS / RATINGS
CE | IP20
INSTALLATION
Rigging: Integrated Rigging Bracket
Working Position: Any (360°)
INCLUDED ITEMS
powerCON Cable
