JBL CSA1300Z
Single-Channel 300W Amplifier - DISCONTINUED

product discontinued

This product has been discontinued by the manufacturer. Please contact us to find a replacement.

*Discontinued

Built for installed sound applications, the CSA 1300Z Single-Channel 300W Amplifier from JBL delivers powerful sound and efficient performance using the Crown’s DriveCore commercial power amplifier technology. Simple to configure, this amplifier provides a DriveCore-based sound solution, which utilizes one small chip that significantly reduces the part count and increases reliability while still maintaining high performance. It provides amplification with a choice of low impedance, 70V or 100V outputs. The amp includes a rack mounting kit for installations to a cabinet, and a RJ45 connector for an optional remote volume control using JBL's CSR-V control module.

Features:
One channel with 300W output
Integrated output transformer to drive 70V or 100V speaker systems
Ideal for commercial and industrial use
Euroblock style input connectors
Barrier strip output connectors
Independent bass and treble controls for each output channel
Remote volume control capability using JBL's CSR-V module and standard Ethernet cable (sold separately)
Space-saving 2 RU design
Capable of RS232 control of volume, stand-by, and mute
Utilizes Crown’s DriveCore technology providing high-quality audio performance with high efficiency
Sleep mode disable function
Energy-efficient amplifier
Sleek look with illuminated rings making knobs easy to see and use
System can be expanded by adding JBL Commercial Series Mixers and Mixer-Amplifiers (sold separately)

Specifications:
Number of Channels 1
Power Rating 4 Ohms / 8 Ohms:
300 W (1 kHz, 0.5% THD)
Load Impedance / Voltage 4 Ohms (Minimum)
70 / 100 V
Performance
Frequency Response 20 Hz to 20 kHz ±1 dB (8 Ohms)
Input Sensitivity Line:
775 mVrms (Balanced, at 8 Ohms)
RCA:
300 mV (at 8 Ohms)
Input Impedance Euroblock:
20 Kilohms (Balanced)
RCA:
10 Kilohms
SNR > 97 dBA
THD < 0.5% (Full Range, at Rated Power)
Crosstalk < -70 dBA (1 kHz)
Signal Processing
EQ 2-Band
Connectivity
I/O Euroblock Balanced/Unbalanced Input
2RCA Summed-Mono Input
Terminal Block Output
Power
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Physical
Operating Temperature 32 to 95°F / 0 to 35°C
Storage Temperature -4 to 185°F / -20 to 85°C
Dimensions 17.0 x 11.0 x 3.5" / 43.0 x 27.0 x 8.9 cm
Weight 13.1 lb / 5.9 kg
