MEGA-Lite presents the Outshine Q500, a powerful IP65 color-changing unit. With a sleek modern housing, this RGBW architectural/ theatrical fixture has the ability to create countless color combinations with even coverage and a compelling color balance due to its 16Bit dimming. Equipped with 48 10W RGBW LEDs, the Outshine Q500 can illuminate a variety of indoor and outdoor settings. The unit has a two segment mode, allowing it to be used for color changing applications. It can create accurate dimming to even the low percentages with its 16Bit Dimming feature. The two channels for color mixing multiplies each color and enables the ability to create an assortment of various colors. This unit makes it possible to create profound saturates as well as warm pastels and exquisite crisp hues and tints, ideal for church, theatrical and outdoor settings. Supplied with Wireless Solutions WDMX, it can be accessorized with a removable barn door and diffusion filter for further control of the light. The Outshine Q500 is designed to create a clean wash effect, smooth color mixing transitions and generate vibrant colors that can transform any venue. Don’t just shine, OUTshine with the Outshine Q500!

SPECIFICATIONS:
ITEM ID:7227
POWER CONNECTION:SEETRONIC IP CONNECTION WITH NEMA 5/15 ADAPTER
IP RATING:IP65
SIGNAL CONNECTORS:SEETRONICS IP65 XLR 3 PIN IN/OUT
FASTENING SYSTEM:2 QUICK RELEASE CLAMP MOUNT 2 OR 1 POSITION
THERMAL:MAXIMUM AMBIENT TEMPERATURE 104º F MAXIMUM SURFACE TEMPERATURE 140º F
WIRELESS:WIRELESS SOLUTIONS IP ANTENNA
LENS:30º
LED QUANTITY:48
LED WATTS:10W
COLOR TYPE:RGBW
DIMMING:16BIT DIMMING
LED LIFETIME:50 TO 80,000 AVERAGE
REFRESH RATE:7000HZ
POWER SUPPLY:110V≈240V 50/60HZ
BALLAST:ELECTRONIC AUTO SWITCHING
POWER CONSUMPTION:WATTS: 272W / AMPS: 2.33
SEGMENT:2 SEGMENT CONTROL
PROTOCOL:DMX 512
DMX CHANNELS:7 MODES OF OPERATION
MODE 3 CHANNELS:RED, GREEN, BLUE
MODE 4 CHANNELS:RED, GREEN, BLUE, WHITE
MODE 5 CHANNELS:DIMMER, RED, GREEN, BLUE, WHITE
MODE 7 CHANNELS:DIMMER, RED, GREEN, BLUE, WHITE, STROBE, MACRO
MODE 8 CHANNELS:RED, RED FINE, GREEN, GREEN FINE, BLUE, BLUE FINE, WHITE, WHITE FINE
MODE 10 CHANNELS:DIMMER, DIMMER FINE, RED, RED FINE, GREEN, GREEN FINE, BLUE, BLUE FINE, WHITE, WHITE FINE
MODE 13 CHANNELS:DIMMER, R1, G1, B1, W1, R2, G2, B2, W2, STROBE, MACRO, DIM CURVE, DIM SPEED
CONTROL OPTIONS:BUILT IN CONTROL VIA DISPLAY

Mega Lighting OUTSHINE Q500-7227 (Mega Lite 7227)
