The ELITE 10 ILDA is a full-colour RGB, diode-based laser system designed for production and touring clients who want to produce high impact aerial beam effects and higher output laser graphics, logos, and text. The ELITE 10 ILDA is integrated into a robust housing, making it ideal for life on the road.
The ELITE 10 ILDA is perfect for large scale indoor venues (up to around 5,000 people capacity) and DJs, clubs, weddings, theatres, or clients and venues needing a high impact laser system at a more aggressive price point. The fixture can also be used both indoors and outdoors for the projection of laser graphics, logos, text and laser billboard advertisements.
ELITE ILDA Series lasers are incredibly easy to set up and use. And can easily be controlled via ILDA or DMX / ArtNET (with Pangolin software).
We recommend using the Pangolin FB3QS or FB4 control hardware with QuickShow software.
What’s in the box
The ELITE 10 package includes all of your main accessories, FREE.
Protective travel case
E-stop safety system and E-stop cables
Product Name: Unity ELITE 10 ILDA
Type Of Laser: Full-colour, Semiconductor diode laser system
Guaranteed Optical Output: 10,500mW
Suitable For: Large-sized venues and indoor events; laser shows and laser graphic displays
Control Signal: ILDA - We recommend Pangolin FB3QS and QuickShow
Scanning System: 35,000 points per second @ 8°
Scan Angle: 50°
Safety: Fully complies with the latest EN 60825-1 and FDA regulations
Weight: 11.7 kg
Package Includes: Heavy-duty flight case, Power cord, 10M ILDA signal cable, E-STOP box with 10M cable, Set of 4 safety keys, 3-pin interlock bypass plug, User guide.
R | G | B [mW]: 2500 | 2700 | 5500
Beam Size [mm]: 6 x 5
Beam Divergence: <1.5mrad [full angle]
Modulation: Analog 100kHz
Power Requirements: 100-230V/50Hz
Consumption: Max. 240W
Operation Temperature: 10-40 °C
Ingress Rating: IP20
System features: All the adjustments such as power output of each colour, X & Y axes invert, X & Y size and position, etc. Scanning system protection, Daisy chain of emergency STOP signal for multiple system "one-hit" operation.
Laser safety features: Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate.
Notice: *Due to Advanced Optical Correction technology used in our laser systems the optical power output of each laser colour within the system may slightly differ from the specification of respective laser module(s) installed. This does not affect the total guaranteed power output.
Dimensions [mm]: Depth: 315
