Wireless Solutions Micro T-1 Transceiver works with W-DMX wireless wash lights, including all WELL and Maverick fixtures, to generate a wireless control signal for both DMX and RDM protocols. These compact devices can also be set up to transmit or receive W-DMX signals to make any fixture or rig wireless. It also features a 5 V USB power supply or can be used with (4) AAA batteries for up to 4 hours in transceiver mode and 8 hours in receiver mode. Indicator LEDs easily show signal strength, battery life, and transceiver or receiver mode.

AT A GLANCE
Transmit and receive 1 universe of W-DMX and RDM protocols
Power with included 5V USB power supply or (4) AAA batteries (not included)
Batteries last for up to 8 hours in receiver mode and 4 hours in transceiver mode
Built in indicator lights for signal and battery strength, as well as operation modes
Can be used directly with any Maverick or WELL fixtures
Can be used to make any lighting system wireless for data

SPECIFICATIONS
CONSTRUCTION / PHYSICAL
Dimensions: 3.94 x 1.57 x 2.65 in (100 x 40 x 65 mm)
Weight: 1.67 lb (800 g)
Exterior Color: dark gray
Housing Material: High-impact flame-retardant polymer

CONNECTIONS
Power Connection: 5V micro USB connector (micro B) to wall wart adapter
Data Connectors: 5-pin XLR

CONTROL
Control Protocol: W-DMX, RDMFrequency (operating): # 2.4 GHz
Universes per device: 1
Number of DMX channels: 512
DMX Latency: <5 ms
Max universe in coexistence: 16
Error correction: yes
DMX Fidelity: yes
Adaptive Frequency Hopping: Yes
W-DMX G3 &G4S compatibility: Yes
Standard range: up to 650 ft (200 m)
Internal antenna: Yes
Sensitivity (0.1% PER): -97 dBm
Modulation method: GFSK

ELECTRICAL
Input Voltage: 9 VDC 1000 mA, (external power supply: 100-230 V 50/60 Hz)

WHAT'S INCLUDED
W-DMX Micro T-1 TRX G5
Micro USB to wall wart adapter
Velcro attachment strap

Chauvet T1 TRX G5
